Dane Techniczne

Rama:: Gambler Alloy 6061; Hydroformed custom butted; PF BB107 / IDS-X DH 12x150mm Dropout; BB height adjustable; ISCG05 / 210mm rear travel
Widelec:: FOX 40 RC2 Factory 27.5”; 203mm travel / Kashima / Air; Hi-Lo Comp / Rebound; 20mm thru axle / Alloy steerer
Amortyzator (Tył):: FOX DH X2 Coil Kashima; Independent high/low comp. and rebound / RVS; custom tuned / 241x76mm; Spring rates S: 400 / M: 450 / L: 500
Przerzutka (Tył):: SRAM XO1 DH; Short cage / 7 Speed
Manetki:: SRAM XO1 DH; Trigger Shifter / 7 Speed
Klamki hamulca:: SRAM Code RSC
Korbowód:: Race Face Atlas; 36T Alloy Chainring DM / 165mm
Oś korbowodu:: Race Face BB107; PF104
Łańcuch:: KMC X11-1
Prowadnica łańcucha:: E.thirteen LG-1+ ISCG05 / w/Taco Alloy backplate
Mostek:: Syncros DH1.5; 35mm / Direct Mount 45-50mm ext.
Kaseta:: SRAM CS PG-720 DH 11-25
Hamulce:: SRAM Code RSC; 4 Piston / 200mm / centerline rotor
Kierownica:: Syncros DH1.5; 35mm / 800mm / 20mm Rise; Syncros Pro DH dual lock-on grips
Sztyca:: Syncros DH1.5 / 31.6mm / Alloy7050
Siodło:: Syncros Tofino 2.0 / CrMo Rails
Stery:: Syncros DH adjustable; Semi integrated / adj +-1° or +-2° with cup; ID 49.6mm / OD 55mm
Opony:: Schwalbe Downhill Evolution Line; Magic Mary 27.5x2.35” Addix Soft; Super Gravity
Koła:: Syncros Revelsoke DH1.5 / 110x20 front / 150x12 rear /; 27.5” / 32H / Tubeless Ready Rims
Orientacyjna waga:: 16,90 kg; (waga orientacyjna dla rozmiaru M)
