Dane Techniczne

Rama:: Genius Carbon / IMP technology / HMF Mainframe; BB92 / Alloy SL 6011 swingarm; VLK Virtual 4 Link kinematic; 27.5” (2.6 & 2.8) and 29” (2.4 & 2.6) tire compatible with; Geo -BB adj.; SW dropouts for Boost 12x148mm; TBC Trunnion box construction
Widelec:: FOX 34 Float Performance Elite Air; FIT4 3-Modes with low Speed adj. / 15x110mm QR axle; tapered steerer / 44mm offset / Reb. Adj. / Lockout /; 150mm travel
Amortyzator (Tył):: FOX NUDE TR EVOL Trunnion; Contessa Custom Tune w. travel / geo adj.; 3 modes: Lockout-Traction Control-Descend; custom Ramp Adjust with linear and progressive setting; DPS / Reb. Adj.; Travel 150-100-Lockout / 185X55mm
Zdalne sterowanie:: SCOTT TwinLoc TSP Technology; Suspension-Seatpost Remote; below Bar / 3 modes / integ. Grip clamp
Przerzutka (Tył):: SRAM X01 / Eagle 12 Speed
Manetki:: SRAM GX Eagle Trigger
Korbowód:: SRAM X1 Carbon DUB Eagle Boost PF; QF 168 / 30T
Oś korbowodu:: SRAM DUB PF integrated / shell 41x92mm
Łańcuch:: SRAM CN GX Eagle
Prowadnica łańcucha:: SCOTT custom
Mostek:: Syncros FL1.5 / Alloy 2014; integrated Spacer & Top Cup / 31.8mm / 6° / 1 1/8”
Kaseta:: SRAM GX / XG1275 / 10-50 T
Hamulce:: Shimano XT M8020 4 Piston Disc; 203/F and 180/R mm SM-RT66 Rotor
Kierownica:: Syncros FL1.5 mini Riser / Alloy 7050D.B.; 12mm rise / 9° / 740mm; Syncros Women Pro lock-on grips
Sztyca:: FOX Transfer Dropper Remote; 31.6mm / S size 100mm / M 125mm / L 150mm
Siodło:: Syncros Savona 2.0 Channel / CRMO rails
Stery:: Syncros FL2.0 Press Fit E2 / Tapered 1.5”-1 1/8”; OD 50/62mm / ID 44/56mm
Opony:: Maxxis Rekon 27.5x2.8"; 60TPI Kevlar Bead / EXO / TR Tubeless ready / Maxx; Terra/Speed
Koła:: Syncros Revelstoke 2.0 6 Bolt; F: 15x110mm, R: 12x148mm Boost; 30mm Tubeless ready rim 28H / XD Driver / DT RWS
Dodatki:: Syncros Trail Fender
Orientacyjna waga:: 13,20 kg; (waga orientacyjna dla rozmiaru S)
